Axalta Corroless ACO Mastic Standard Grade is a solvent free, high build, two pack polyurethane mastic for steel, for the repair of pipe coatings and the coating of field joints.
Axalta Corroless ACO Mastic Standard Grade is suitable for the use for the coating of field joints, repair of damaged coatings, filling of holes and cracks, on steel pipelines and other steel structures. For faster-cure repairs use Acothane Mastic Rapid grade, and for higher temperatures and hot surfaces, use Corroless ACO Mastic TG grade.
All surfaces to be coated should be dry and cleaned as necessary to remove all oil, grease, salts, weld flux or other contamination. Where necessary, remove weld spatter and grind smooth all sharp edges and weld seams
Steel: blast clean to minimum Sa2½ (ISO 8501-1:2007), surface profile depth 75-100μm. Mechanical tools may also be used providing a profile of minimum 75μm. Do not polish the steel surface
Overlap onto existing pipeline coating: remove any loose material to establish a firm edge. Feather sound coating and abrade surface to provide a key. Thoroughly abrade to remove gloss, surface contaminants etc. by suitable method (sweep blasting, abrasive disking etc.)
Concrete: remove all laitance and other contaminants by most appropriate methods. Ensure the concrete is dry to a reading of <16% on the Wood Moisture Equivalent (WME) scale. Prime with Corroless ACO LV Sealer.
- Meets the requirements of GBE/CW6 Part 1 for External Pipe Protection
- BS6920 Factory and site application and WRAS water fittings directory
- Meets the performance requirements of BS EN 10290 and AWWA C222
- Malaysian SPAN approved
|VOC Content:||0 g/litre|
|Theoretical Coverage:||1.0 m2/litre with DFT & WFT of 1mm / 0.2 m2/litre with DFT & WFT of 5mm|
|Wet Film Thickness (WFT):||1mm / 5mm|
|Dry Film Thickness (DFT):||1mm / 5mm|
|Pot Life:||Approx. 12 min at 25°C, 8 min at 30°C|
|Dust Free:||1 hours at 20°C (applied to 1mm DFT)|
|Hard Dry:||4 hours at 20°C (applied to 1mm DFT)|
|Overcoatable:||After 1 hour at 20°C (applied to 1mm DFT)|
|Fully Cured:||7 days at 20°C (applied to 1mm DFT)|
|Cleaner / Thinner:||Clean with Thinner No. 4 / Do not thin|
|Shelf Life:||Minimum 24 months if stored as above in unopened containers|
|Packaging:||Available in 10 x 1 Litre|
The manufacturers data sheets are available for download from this website. It is your responsibility to read and understand all aspects of the data sheets before you place an order and prior to application. Please pay special attention to the preparation, mixing and application temperatures of the product, cleaning of substrate and environmental factors such as temperature, rain etc. Quoted coverage rates are based on the manufacturers theoretical rates and may vary depending upon substrates absorption, texture and application. We always recommend a test is carried out to ensure suitability.
Customer further agrees that Promain have no liability for any errors or omissions contained within the Product Data Sheets and are not liable for failure due to misapplication or inadequate substrate cleaning and preparation. For more information please refer to our Terms & Conditions.
