Download the manufacturer specifications for NORSOK M-501 certified systems below:
Hempel | International Paints | Jotun | PPG | Sherwin Williams
Guide To Working In Confined Spaces
PPG SigmaPrime 200
A two component multipurpose polyamide anti-corrosive epoxy paint system from PPG.
PPG SigmaPrime 700
A two component multi purpose polyamide cured anti-corrosive epoxy paint system from PPG.
Sherwin Williams Epidek M153 - Formerly Leighs
A hard wearing, anti slip extra heavy duty deck coating system. Reaches NORSOK M-501 and BS.476 Part 7: Surface spread of ...
PPG SigmaShield 1090
A two component flint reinforced solvent free polyamine cured, epoxy compound suitable for the protection of steel and con...
Jotun Jota Armour Standard
A 3 part, high solids, surface tolerant, abrasion resistant anti-corrosive epoxy coating with a selected blend of fused al...
Jotun Penguard Express
A two component fast drying coating. Can be applied on steel, aluminium and concrete at sub zero surface temperatures.
Zinga 96% Zinc Cathodic Protection Galvanizing Paint
A one pack coating that contains 96% zinc to provide cold galvanizing cathodic protection of ferrous metals.
Sherwin Williams Macropoxy C425V2 - Formerly Leighs Epigrip
A high build, 2 pack epoxy, zinc phosphate primer / buildcoat for the anti corrosive protection of steel.
Sherwin Williams Macropoxy 646 Epoxy Primer Finish
A versatile high performance polyamide cured epoxy designed to fulfil the needs of both new construction and maintenance p...
Sherwin Williams Macropoxy P200 Epoxy Glass Flake, 400 Litres
A high solids, 2 pack epoxy comprising of lead free colouring pigments, micronised glass flake and anti corrosive pigments.
PPG SigmaGuard 730
A two component, high solids polyamine cured phenolic epoxy coating for use as a tank coating when short, low temperature ...
Sherwin Williams Acrolon 1850 Acrylic Epoxy Finish
A two pack isocyanate free finish based on an acrylic epoxy binder system. NORSOK M501 Rev 6 System 1.
Sherwin Williams Zinc Clad IV EU Formerly M501
An 2 pack epoxy zinc rich anti corrosive primer for the protection of steel surfaces.
Sherwin Williams Firetex M90/02 Epoxy Intumescent
A two pack, solvent free, thick film epoxy exterior intumescent coating that provides passive hydrocarbon fire protection ...
Sherwin Williams Heat-Flex Hi-Temp 1200
A 1 pack inert multipolymeric matrix coating that outperforms alternatives in combating corrosion under insulation (CUI) a...
Jotun Barrier 80
A fast drying, anti corrosive, high solids 2 part polyamide cured zinc rich epoxy coating.
Jotun Jotamastic 90 WG Wintergrade
A corrosion, abrasion, chemical and water resistant coating, suitable for interior and exterior use.
PPG SigmaCover 380
A universal epoxy anti-corrosive primer based upon pure epoxy technology suitable for ballast tanks and marine structures.
Jotun Jotamastic 90
A corrosion, abrasion, chemical and water resistant coating, suitable for interior and exterior use.
PPG NovaGuard 4801
A two component, glass flake reinforced novolac vinyl ester coating for new or old steel with excellent resistance to high...
PPG SigmaZinc 68 SP
A two component, high solids polyamine adduct cured zinc rich epoxy primer for aggressive environments.
PPG Phenguard Subsea 610
A two component, high build, amine adduct-cured novolac phenolic epoxy primer for subsequent coats of PPG Phenguard Subsea...
PPG SigmaCover 410
Two component high solids, high build, polyamide cured epoxy coating designed for general purpose protection to steel and ...
PPG SigmaDur 520
A 2 pack high build semigloss aliphatic acrylic polyurethane finish, Highways Approved Item No.169.
PPG SigmaDur 540 - Formerly Amercoat 229
A two component high gloss VOC compliant epoxy acrylic finish. Highways Approved Item No.167.
PPG PSX 700 Engineered Siloxane
For steel from PPG Sigma, Ameron. Highways Approved Item No.185.
PPG SigmaGuard CSF 585
WRAS Approved for drinking water. A two component solvent free amine cured epoxy coating.
PPG SigmaGuard CSF 650
A two part, solvent free, amine cured, epoxy coating designed for the coating of tanks that contain oil/ballast and alipha...
| System 1 (pre-qualified) | Carbon steel with maximum operating temperature < 120°C (248°F) Structural steel Exteriors of equipment, vessels, piping and valves (not insulated) |
| System 2 | Carbon steel surfaces exposed to operating temperatures > 120°C (248°F) |
| System 3A-3G (System 3B pre-qualified) | Internal surface of carbon steel tanks |
| System 4 (pre-qualified) | Walkways, escape routes and lay down areas |
| System 5A (pre-qualified) | Epoxy-based fire protection |
| System 5B (pre-qualified) | Cement-based fire protection |
| System 6A | Uninsulated stainless steel when painting is required. Aluminum when painting is required |
| System 6B | Hot-dipped, galvanized steel when painting is required |
| System 6C | Insulated stainless steel piping and vessels at temperatures < 150°C (302°F) |
| System 7A (pre-qualified) | Carbon and stainless steel in the splash zone |
| System 7B (pre-qualified) | Submerged carbon and stainless steel ≤ 50°C (122°F) |
| System 7C (pre-qualified) | Submerged carbon and stainless steel > 50°C (122°F) |
| System 8a |
Structural carbon steel with maximum operating temperature ≤ 80°C (176°F) in internal and fully dry and ventilated areas |
| System 8b |
Structural carbon steel with maximum operating temperature ≤ 80°C (176°F) in fully dry and ventilated areas |
| System 9 | Bulk-supplied carbon steel valves with maximum operating temperature up to 150°C (302°F) |
