Centrecoat Armourcoat 3-350 is a 2 part, 100% solids epoxy floor coating offering excellent abrasion and chemical resistance. Provides a tough, hard wearing coating for medium duty traffic giving high film build and wear resistance.
Centrecoat Armourcoat 3-350 is formulated for medium duty flooring areas requiring an easy to clean, tough and durable coating with excellent chemical resistance. Centrecoat Armourcoat 3-350 is ideal for as warehouses, factories, workshops, showrooms, packing and storage areas.Suitable for application onto concrete and polymer modified cementitious screeds.
- Protects concrete from oil and chemical spillages
- High build with excellent wear resistance
- 100% solids
- Easy application - no need for solvent/thinners
- Gloss, easy to clean finish
- Slip-resistant options available
- Nonyl phenol free - reduced hazard
Centrecoat Armourcoat 3-350 can also be used as a seal coat for broadcast systems such as intermediate car park decks. Armourcoat 3-350 is suitable for regular foot traffic, light duty fork lift truck traffic and occasional hard plastic-wheeled trolleys.
BS 8204 Part 6 Synthetic Resin Flooring Type Categorisation
|FeRFA No||Type||Description||Duty||Typical Thickness|
|1||Floor Seal||Applied in 2 or more coats. Generally solvent or water borne||LD||> 150μm|
|2||Floor Coating||Applied in 2 or more coats. Generally solvent free||LD / MD||150 - 300μm|
|3||High build floor coating||Applied in 2 or more coats. Generally solvent free.||MD||300 - 1000μm|
|4||Multi-layer flooring||Aggregate dressed systems based on multiple layers of floor coatings or flow-applied flooring, often described as sandwich systems||MD / HD||> 2mm|
|5||Flow-applied flooring||Often referred to as ‘self-smoothing’ or ‘self-levelling’ flooring and having a smooth surface||MD / HD||2 - 3mm|
|6||Resin screed flooring||Trowel-finished, heavily filled systems, generally incorporating a surface seal coat to minimise porosity||MD / HD||> 4mm|
|7||Heavy duty flowable flooring||Having a smooth surface||HD / VHD||4 - 6mm|
|8||Heavy duty resin flooring||Trowel-finished, aggregate filled systems effectively impervious throughout their thickness.||VHD||> 6mm|
LD – light foot traffic, occasional rubber tyre vehicles, MD – regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys, HD – constant fork lift truck traffic, hard plastic wheeled trolleys, some impact, VHD – severe heavily loaded traffic and impact
Concrete substrates must have a minimum compressive strength of 25 N/mm2 and a minimum pull-off strength of 1.5 N/mm2 and be dry (≤ 4% by weight), clean and free of surface laitance and contaminants such as dirt, dust, loose material, oil, grease, poorly bonded coatings and surface treatments. Concrete must include a functional damp-proof membrane and be free of rising moisture.
Inadequate preparation will lead to loss of adhesion and failure. In coatings, there is a tendency for the finish to mirror imperfections in the substrate. Grinding, or light vacuum-contained shot-blasting is therefore preferred over planning for these systems. Weak concrete must be removed and voids filled with a suitable repair material. High spots must be removed e.g. by grinding. Excessively porous concrete should be primed using Armourcoat 3-350 Primer. If in doubt, apply a test area first.
Materials should be stored at 15°C to 25°C for a minimum of 8 hours prior to use. Mechanically premix the coloured resin component before use. Add the hardener component to the coloured resin component and mix using a low speed electric mixer (300 - 500 rpm) for at least 3 minutes until homogeneous. Use a spatula to scrape the sides and bottom of the mixing vessel several times during mixing, as unmixed material will result in uncured patches in the final finish. Pouring the mixed material into a second mixing container and mixing again will greatly reduce the possibility of soft spots. Do not add solvent/thinners to the product.
Best results are obtained in warm conditions (minimum 15°C). Apply with a short pile roller working well into the surface taking care not to exceed the coverage rate. Edges and difficult to reach areas may be applied thinly by brush. The second coat should be applied at right angles to the first. An anti-slip finish may be achieved by fully sprinkling the first coat with kiln dried silica sand at 3 - 4 kg/m2. Allow the first coat to fully cure (24 hours at 15°C or longer in colder temperatures) then remove all excess sand with a stiff broom and vacuum. Apply a second coat to encapsulate the grains, using a squeegee followed by back-rolling with a short pile roller.
- Category 3 FeRFA flooring
|Stock Colours:||Midnight Blue, Chelsea Blue, Mid Blue, Light Blue, Green, Yellow, Buff, Sahara, Red, Light Grey (Close to RAL 7035), Mid Grey (Close to RAL 7046), Dark Grey (Close to RAL 7015), Charcoal, Black|
|Tintable:||Call our sales team to check. Please note, bespoke tints are non refundable / exchangeable|
|VOC Content:||140 g/L|
|Suitable Substrates:||Concrete and cementitious screeds.|
|Application Method:||Brush, Short Pile Roller|
0.25 kg/m2 per coat
Coverage will vary depending on the texture and porosity of the substrate, film thickness and application technique. Two coats are normally sufficient but on very porous substrates, an initial coat of Armourcoat 3-350 should be applied.
|Wet Film Thickness (WFT):|
|Dry Film Thickness (DFT):||350 microns in 2 coats|
|Pot Life:||25 minutes at 20°C|
|Light Traffic:||24 hours at 20°C|
|Overcoatable:||Between 16 - 36 hours at 20°C|
|Fully Cured:||7 days at 20°C|
|Cleaner / Thinner:||Tools and equipment should be cleaned whilst the resin is still wet using Armourcoat Thinner I.|
12 months if stored in accordance with the below recommendations.
Materials should be stored in their original, unopened containers in a dry weatherproof building maintained at 10°C to 30°C on pallets and away from walls. Consignments should be used in order of batch number. Protect from frost.
|Packaging:||Available in 5 Kg|
The manufacturers data sheets are available for download from this website. It is your responsibility to read and understand all aspects of the data sheets before you place an order and prior to application. Please pay special attention to the preparation, mixing and application temperatures of the product, cleaning of substrate and environmental factors such as temperature, rain etc. Quoted coverage rates are based on the manufacturers theoretical rates and may vary depending upon substrates absorption, texture and application. We always recommend a test is carried out to ensure suitability.
Customer further agrees that Promain have no liability for any errors or omissions contained within the Product Data Sheets and are not liable for failure due to misapplication or inadequate substrate cleaning and preparation. For more information please refer to our Terms & Conditions.
