Centrecoat ArmourCoat HB 3-400 is a two part, High Build, virtually solvent free epoxy floor paint offering a tough, hard wearing gloss finish for medium duty traffic floors, giving high film build and good wear resistance.
Centrecoat ArmourCoat HB 3-400 is a two pack virtually solvent free epoxy industrial floor paint offering excellent abrasion and chemical resistance. ArmourCoat HB 3-400 provides a tough,high build, hard wearing coating for medium duty traffic giving high film finish suitable for warehouse floors, garages and even car parking spaces.
- Protects concrete from oil and chemical spillages
- High build with excellent wear resistance
- Virtually solvent free
- Available in a wide range of colours
- Glossy easy to clean finish
- Slip-resistant options available
Centrecoat ArmourCoat HB 3-400 is formulated for medium duty floors requiring an easy to clean, tough and durable coating with excellent chemical resistance such as warehouses, factories, workshops, showrooms, packing and storage areas. Centrecoat ArmourCoat HB 3-400 can also be used as a sealcoat for broadcast systems such as intermediate car park decks. ArmourCoat HB 3-400 is suitable for regular foot traffic, fork lift truck traffic and occasional hard plastic-wheeled trolleys.
BS 8204 Part 6 Synthetic Resin Flooring Type Categorisation
|FeRFA No||Type||Description||Duty||Typical Thickness|
|1||Floor Seal||Applied in 2 or more coats. Generally solvent or water borne||LD||> 150μm|
|2||Floor Coating||Applied in 2 or more coats. Generally solvent free||LD / MD||150 - 300μm|
|3||High build floor coating||Applied in 2 or more coats. Generally solvent free.||MD||300 - 1000μm|
|4||Multi-layer flooring||Aggregate dressed systems based on multiple layers of floor coatings or flow-applied flooring, often described as sandwich systems||MD / HD||> 2mm|
|5||Flow-applied flooring||Often referred to as ‘self-smoothing’ or ‘self-levelling’ flooring and having a smooth surface||MD / HD||2 - 3mm|
|6||Resin screed flooring||Trowel-finished, heavily filled systems, generally incorporating a surface seal coat to minimise porosity||MD / HD||> 4mm|
|7||Heavy duty flowable flooring||Having a smooth surface||HD / VHD||4 - 6mm|
|8||Heavy duty resin flooring||Trowel-finished, aggregate filled systems effectively impervious throughout their thickness.||VHD||> 6mm|
LD – light foot traffic, occasional rubber tyre vehicles, MD – regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys, HD – constant fork lift truck traffic, hard plastic wheeled trolleys, some impact, VHD – severe heavily loaded traffic and impact
Substrates in contact with the ground must incorporate a functional damp proof membrane in accordance with CP102 or in the case of basement floors, BS 8102. The base should have a relative humidity at the surface of no more than 75% when measured according to BS 8203.
After surface preparation, substrates must exhibit readings of 25 or above when tested using a rebound hammer in accordance with BS EN 12504-2 type N and pull-off strengths in excess of 1.5 N/mm2 when tested in accordance with BS EN 13892-8. Fine concrete screeds should be designed and constructed in accordance with BS 8204-1 and should not contain water repellent admixtures. Unmodified sand cement screeds or those based on calcium sulphate are unsuitable.
Substrates must be clean, dry and free of surface laitance and contaminants such as dirt, oil, grease, poorly bonded coatings and surface treatments. Inadequate preparation will lead to loss of adhesion and failure. In coatings, there is a tendency for the finish to mirror imperfections in the substrate. Grinding, or light vacuum-contained shot-blasting is therefore preferred over planing for these systems.
Materials should be stored at 15°C to 25°C for a minimum of 8 hours prior to use. Pre-mix the coloured resin component before use. Add the hardener component to the coloured resin component and mix using a low speed electric mixer (200 - 500 rpm) for at least 3 minutes until homogeneous. Use a spatula to scrape the sides and bottom of the mixing vessel several times as unmixed material will result in uncured patches in the final finish.
Mixed material must be used immediately. (minimum 15°C). Apply with a medium pile simulated sheepskin roller working well into the surface taking care not to exceed the coverage rate. Edges and difficult to reach areas may be applied thinly by brush. An anti-slip finish may be achieved by broadcasting the first coat to saturation, with kiln dried silica sand at 3 - 4 kg/m2. Allow the first coat to cure for 24 hours at 15°C (or longer in colder temperatures) then remove all excess
sand with a stiff broom and vacuum. Apply a second coat to encapsulate the grains.
- Certified for FeRFA Type 3: High Build Floor Coating; Medium Duty; 300 - 1000 microns.
|Stock Colours:||Mid Grey and Light Grey|
|Tintable:||Yes, to most RAL or British Standard codes. Please note, bespoke tints are non refundable / exchangeable|
|VOC Content:||<500 g/L|
|Suitable Substrates:||Concrete and polymer modified cementitious screeded floors|
|Application Method:||Medium Pile Sheepskin Roller|
|Theoretical Coverage:||1st coat - 375 g/m2
2nd coat - 250 g/m2
|Wet Film Thickness (WFT):|
|Dry Film Thickness (DFT):||Approximately 400 microns from two coats|
|Pot Life:||25 minutes at 20°C|
|Cure Time To Pedestrain Traffic:||24 hours at 20°C|
|Overcoatable:||Between 16 - 36 hours at 20°C|
|Fully Chemical Resistance:||7 days at 20°C|
|Cleaner / Thinner:||Tools and equipment should be cleaned whilst the resin is still wet with a suitable solvent.|
|Shelf Life:||12 months if stored in accordance with the above recommendations.|
|Packaging:||Available in 5 Kg. Other sizes available on request.|
The manufacturers data sheets are available for download from this website. It is your responsibility to read and understand all aspects of the data sheets before you place an order and prior to application. Please pay special attention to the preparation, mixing and application temperatures of the product, cleaning of substrate and environmental factors such as temperature, rain etc. Quoted coverage rates are based on the manufacturers theoretical rates and may vary depending upon substrates absorption, texture and application. We always recommend a test is carried out to ensure suitability.
Customer further agrees that Promain have no liability for any errors or omissions contained within the Product Data Sheets and are not liable for failure due to misapplication or inadequate substrate cleaning and preparation. For more information please refer to our Terms & Conditions.
