Hempel Hempadur 45143 Low Temperature

Part A and B: UN1263 (Class: 3, Pk Grp: III)
A two-component, polyamide adduct cured epoxy paint with good wetting properties and low water permeability. For internal applications down to -10°C.
Available in 5 and 20 Litres
From £64.84 £54.03
In stock
Only %1 left
Product Description

Hempel Hempadur 45143 is a two-component, polyamide adduct cured epoxy paint with good wetting properties and low water permeability. Ideal for application in freezers or low temperature areas internally down to -10°C.

Hempadur 45143 is self priming and forms a hard and tough coating with good resistance against abrasion and impact as well as to seawater, mineral oils, aliphatic hydrocarbons and splashes from petrol and related products.

Best Uses

Hempel Hempadur 45143 is suitable as a high build primer, intermediate and/or finishing coat in (heavy duty) paint systems according to specification. Hempadur 45143 is also suitable for repair and maintenance work at application temperatures above -10°C/15°F on hatch covers, decks, in cargo holds, etc. Another use is as a ballast tank coating. Hempadur 45143 is intended for use in cold/temperate climates, Hempadur 45141 for warmer climates - see Application Guide via data sheets tab. Harmless to grain cargoes.

Suitable for industrial floors. Ideal for application in freezers or low temperature areas internally down to -10°C.


In order to obtain the best performance, abrasive blast cleaning is recommended. However, HEMPADUR 45141/45143 may be applied on rusty steel surfaces where higher performance is needed than obtainable with conventional coatings but where mechanical cleaning and dust removal can only be carried out (beside the removal of salts and of oily contaminants). Remove oil and grease with suitable detergent, salt and other contaminants by (high pressure) fresh water cleaning. Spot repair as necessary.

For Full Coating

Compatibility with old system: HEMPADUR 45141/45143 may exceptionally be applied directly on top of an old alkyd paint system, provided this is tightly adhering. It is furthermore preferable that the old system is less than approximately 500 microns in film thickness. A test patch should always be performed before full coating is decided. Even old chlorinated rubber and vinyl systems may be overcoated, but with an inherent risk of later tendency to "liftings" along mechanical damage and similar weaknesses.
Removal of old system: Full coating after mechanical removal of an old paint system is possible too. Yet, it must be considered that mechanical cleaning may produce a very smooth surface, giving reason to reduced adhesive forces.

Technical Details


  • NATO Approval No. 8010-99-602-7280 (10000 White 5 Litres)
  • NATO Approval No. 8010-99-535-5832 (50630 Red 5 Litres)

Technical Info

  • Recommended for use with airless sprayers with a nozzle size of .021"-.023"
  • Pot Life: 2 hours at 15°C. However if using a 20 litre drum practical pot life may be shorter.
  • Drying Time: 7 hours at 20°C, Curing Time: 7 days
Components: Two Part
Type: Polyamide Adduct Cured Epoxy
Finish: Semi Gloss
Stock Colours: 50630 Red
Tintable: Yes, please call to confirm shades. Please note, bespoke tints are non refundable / exchangeable.
VOC Content: 367.0g per Litre
Volume Solids: 60%
Suitable Substrates: For new steel or maintenance
Application Method: Brush or Airless Spray
Theoretical Coverage: 4 m2 per litre at 150 microns
Wet Film Thickness (WFT): 250 microns
Dry Film Thickness (DFT): 150 microns
Induction Time: -
Pot Life: 2 hours at 15°C
Touch Dry: 11 hours at 5°C
Overcoatable: See product data sheet table
Fully Cured: 20 days at 5°C
Cleaner / Thinner: Thin with HEMPEL 08450 (5%). Clean with HEMPEL'S TOOL CLEANER 99610 or HEMPEL'S THINNER 08450
Shelf Life: 3 years for Base and Hardener from date of production
Packaging: Available in 5 and 20 Litres

Related Products
